Wheel Loader 890T
Prospekt stroje ke stažení.pdf| Weight of machine | 31 750 kg |
|---|---|
| Engine | Cummins QSX12, Stage V |
| Power | 287 kW |
-
Programmable hydraulic control suitable for different operating styles.
-
Ride control system and new bucket design enhance material retention and improve productivity.
-
5 speed ZF transmission provides performance in heavy duty applications, lock-up converter reduces fuel consumption for rehandling.
-
Integral payload weigh system and auto dig function increase loading efficiency and productivity.
-
Z-bar linkage with high pressure hydraulics for increased breakout force.
-
Heavy-duty wet type brake axle and braking system ensure the reliability and durability, axle cooling is optional for tougher applications.
-
Fully-sealing and micro-pressuring system ensures the cab is clean and quiet. Silicone oil shock absorber reduces vibration and improves ride comfort.
-
Improved ergonomics for cab design with all control switches in easy reach of the operator.
Dimensions
| A: Max. hinge pin height | 4 609 mm |
|---|---|
| B: Dump clearance at full height discharge | 3 332 mm |
| C: Dump reach at full height discharge | 1 433 mm |
| D: Maximum digging depth, bucket level | 127 mm |
| E: Ground clearance | 442 mm |
| G: Wheelbase | 3 700 mm |
| H: Cab height | 3 790 mm |
| K: Width over tires | 3 170 mm |
| L. Length with bucket down | 9 737 mm |
| M. Turn angle, either side | 38° |
| P. Rear angle of departure | 25° |
| R1. Turning radius, bucket carry | 7 822 mm |
| R2. Turning radius, outside of tire | 6 958 mm |
| S3. Bucket rollback at maximum height | 60° |
| S4. Maximum dump angle at full height | 45° |
LiuGong 890T (Stage V) – Technical Specification
-
Operating weight: 31,750 kg
-
Standard bucket: 5.4 m³
-
Maximum gross power: 287 kW @ 1,800 rpm
-
Net power: –
-
Rated load capacity: 9,500 kg
-
Hydraulic cycle time: 11 s
-
Arm raise time: 6 s
-
Maximum travel speed (forward): 41.9 km/h
-
Tipping load (full turn): 21,150 kg
-
Bucket breakout force: 270 kN
-
Dump clearance at full height: 3,332 mm
-
Dump reach at full height: 1,433 mm
Engine
-
Model: Cummins X12
-
Emissions standard: EU Stage V
-
Aspiration: Turbocharged with air-to-air intercooler
Dimensions
-
Length with bucket on ground: 9,637 mm
-
Width over tires: 3,170 mm
-
Cab height: 3,790 mm
-
Turning radius (outside of tires): 6,958 mm
Bucket Capacity
-
Capacity range: 4.0 – 9.0 m³
-
General purpose bucket: 5.4 m³
